TS 5000 ECline

ECline guide rail TS 5000 * For TS 5000 ECline closer body with opening assistance

ECline guide rail TS 5000
  • Opening assistance for easy opening and comfortable passing of the door
  • Opening assistance can be switched off for doors with wind load or pressure differences
  • Easy to replace with the standard guide rail
  • With screwed sliding block
Contact us

ECline guide rail TS 5000

For TS 5000 ECline closer body with opening assistance

Application Areas

  • Barrier-free access with strongly decreasing opening torque
  • Single leaf doors
  • Installation on hinge side
  • Right and left single-action doors

Technical data

ECline guide rail TS 5000
Length 452.5 mm
Width 33 mm
Height 30 mm
Integrated opening assistance Yes
Hold-open function Optional
Opening assistance can be switched off Yes

Downloads

* Notice about the products displayed

The products mentioned above may vary in form, type, characteristics and function (design, dimensions, availability, approvals, standards etc.) depending on the country. For questions please contact your GEZE contact person or send us an E-Mail .
