F 1200+ drive Powerful ventilation drive for convenient and safe automation of aluminum bottom-hung and tilt-turn windows
- Tilt and locking function plus manual turn function combined in one drive
- Achieves the full opening width of 180 mm for all leaf heights
- Ventilation with variable adjustment – from gap ventilation to the tilted end position
- Safe use thanks to limitation of bottom opening width and authorised operation of the turn function
- Excellent operating comfort thanks to non-powered, barrier-free and safe operation, variable drive positioning and user feedback
- Proximity sensor activates the control panel when the user approaches
- Brightness sensor adjusts illumination of the control panel to the ambient brightness
- Low-noise drive improves indoor comfort
- IQ windowdrive - intelligent drive control
Powerful ventilation drive for convenient and safe automation of aluminum bottom-hung and tilt-turn windows
The intelligent window drive offers great creative freedom even for large and heavy turn-and-tilt and bottom-hung windows: the powerful, yet very quiet drive can move the window to the desired tilted position and lock and unlock the window, so that a manual turning position can be set via the innovative operating element. The GEZE IQ box KNX makes integration into automated control concepts possible – for automated, natural ventilation solutions.
Application Areas
- Automation of large and heavy windows for natural ventilation
- Can be used for natural ventilation (24 V) in the façade area
- For inward opening turn and tilt and tilt windows
- Installation on aluminium windows
- Leaf installation
Installation situations in reference objects and videos
F 1200+
Easily and safely operate heavy windows: Modern façade design relies on floor-to-ceiling window elements that create maximum daylight and comfort in rooms. The F 1200 is the ideal window hardware for this trend, allowing for the operation of large and heavy turn-and-tilt windows. It provides a pleasant and comfortable indoor climate through natural ventilation – even at airy heights.
F 1200+
The intelligent window drive is also designed for large, heavy turn-and-tilt and bottom-hung windows up to 3.50 metres high, with a 2.40 metre leaf width and 200 kilogramme leaf weight. This powerful and very quiet drive can bring the windows into the desired tilt position, lock and unlock the window, providing the option of manually adjusting the turning position.
F 1200+ window drive
Modern façade design calls for floor-to-ceiling window elements that ensure maximum daylight and comfort in rooms. The F 1200 is the ideal window fitting system for this trend, allowing for the operation of large and heavy turn-and-tilt windows. It provides a pleasant and comfortable indoor climate through natural ventilation – even at airy heights. The new F 1200+ drive is now available for convenient opening and locking of large windows, making operation even easier, faster and safer. © GEZE GmbH
F 1200+ window drive
A proximity sensor activates the control panel as soon as a person approaches. The capacitive touch buttons and an LED display make operation a breeze. An additional brightness sensor adjusts the LED display to the lighting in the room, and provides information both on the status of the drive and the opening width of the window. © GEZE GmbH
F 1200+ window drive
Operate heavy windows easily and safely: The F 1200+ has a very powerful motor that can turn and tilt even heavy window elements up to 200 kg leaf weight – while remaining extraordinarily quiet. © GEZE GmbH
Technical data
| F 1200+ drive | |
| Dimensions | 505 x 52 x 45 mm |
| Housing material | Aluminum |
| Opening width (max.) | 180 mm |
| Opening speed ventilation | 11 mm/s |
| Closing speed (max.) | 15 mm/s |
| Unlocking force in turning position | 500 N |
| Locking and unlocking force in tilted position | 700 N |
| Panel weight (max.) | 150 kg/m² |
| Operating voltage | 24 V DC +/-10% |
| Current consumption | 2.5 A |
| Power consumption | 60 W |
| Duty rating | 30 % |
| Number of cores | 3 cores |
| Service temperature | -5 - 70 °C |
| IP rating | IP40 |
| protection rating | III |
| Adjustable opening speed (ventilation) | Yes |
| Overload cut-off | Yes |
| KNX ability | Yes |
| Bottom-hung window INWARD-opening leaf installation | Yes |
| Side-hung window INWARD-opening door leaf installation | Yes |
