TSA 355 Manual door
TSA 355 Manual door * Manual revolving door system for three- or four-leaf doors
- Customised choice of diameter, passage height and surfaces
- Extensive equipment options
- Simple installation of the door system without lifting tools
- Fast commissioning thanks to pre-cabled and configured sensors
Manual revolving door system for three- or four-leaf doors
Note: The product listed may not be available in your country. Please contact your GEZE contact person or send us an e-mail.
Application Areas
- Three- and four-leaf door systems
- Interior and exterior doors with high access frequency
- Representative building entrances with large incidence of light
- Façades with slim post-rail constructions
- Diameter from 1800 to 3200 mm possible
Technical data
| TSA 355 Manual door | |
| Manual operation | Yes |
| With speed limiter (optional) | Yes |
| Break-out function (BO) | Yes |
| Inner diameter (min.) | 1700 mm |
| Inner diameter (max.) | 3100 mm |
| For 3-leaf door systems | Yes |
| For 4-leaf door systems | Yes |
| Clear passage height | 3000 mm |
| Canopy height (min.) | 150 mm |
| Side elements version | 8 mm LSG |
| Version of roof structure | optical sheet metal covering, waterproof roof with waterspout |
| Illumination | with roof variant, according to customer wishes |
| Floor covering | Entrance mat, Entrance mat according to customer wishes |
| Hot-air curtain system | hot water air curtain, Electric air curtain, possible, depends on the ceiling construction |
| Night-time closer layout | Outside |
| Night-time closer type | Manual |
| Night-time closer design | 8 mm LSG |
| Lock | Manual |
| Door handles horizontal or vertical | Yes |
| Floor ring | Yes |
Downloads
* Notice about the products displayed
The products mentioned above may vary in form, type, characteristics and function (design, dimensions, availability, approvals, standards etc.) depending on the country. For questions please contact your GEZE contact person or send us an E-Mail .
