Slimdrive SL-FR-RC2 * Automatic linear sliding door system with burglar resistance in accordance with resistance class RC2

Slimdrive SL RC 2 Single and double leaf sliding door systems. Inside and exterior doors with the highest safety demands. Certified burglar resistance according to resistance class RC 2. Function RC 2 is only available in the "night mode" mode of operation where the door is locked via the rod locking.
  • Escape route function with redundant drive design
  • Certified burglar resistance according to resistance class RC2
  • The RC2 function is only available in the "Night" mode of operation, since the door does not have to fulfil any escape route stipulations
  • Equipped with a rod locking and reinforced profile components
  • Very quiet running, low-wear direct current drive with a height of only 7 cm
  • Can be networked via CAN bus and integrated into building technology management systems
Show more
  • Independent error recognition and recording
  • Freely configurable inputs and outputs for different functions
  • Integrated, rechargeable battery for emergency opening in case of safety-relevant faults, such as power failure
  • Self-cleaning roller carriage reduces maintenance effort and costs
Contact us

Automatic linear sliding door system with burglar resistance in accordance with resistance class RC2

Application Areas

  • Single and double leaf sliding door systems along escape and rescue routes
  • Interior and exterior doors with maximum safety requirements
  • Opening widths of 800 to 3000 mm possible
  • Door leaf weight of up to 120 kg per leaf
  • Suitable profile systems are fine-framed profile systems with ISO and mono glass, in accordance with the RC2 resistance class
  • Suitable for various profile systems

Technical data

Slimdrive SL-FR-RC2
For 1-leaf door systems Yes
For 2-leaf door systems Yes
Fine-framed insulating glass Yes
MONO glass fine-framed Yes
Depth 190 mm
Leaf weight (max.) 1-leaf 120 kg
Leaf weight (max.) 2-leaf 120 kg
Opening width 1-leaf 700 mm - 3000 mm
Opening width 2-leaf 900 mm - 3000 mm
Service temperature -15 - 50 °C
IP rating IP20
Disconnection from mains Main switch in the drive
Standard conformity AutSchR, DIN 18650, DIN EN ISO 13849: Performance Level D, EN 16005
